Panoramic Focusing Color Doppler Machine With 4D Function Optional

Place of Origin : China

Brand Name : BIO

Model Number : 5000N

MOQ : 1 unit

Delivery Time : 7 working - days since getting full payment

Payment Terms : Credit card, Paypal, T/T

Supply Ability : 100 units / month

Packaging Details : Carton (42*43*15cm) 6kgs

Display : 15”LCD monitor

Transducer frequency : 2-12Mhz

Gray sacle : 256

Depth display : ≥250mm

Dynamic range : 0~120dB adjustable

Image storage : ≥160G

Pseudo color encoding : 16 kinds can optional

Gain adjusts : 8 segments

Focus position : dynamic electron focusing

Contact Now

Panoramic Focusing Color Doppler Machine With 4D Function Optional

Quick Detail

1.Easy to carry,small and light with comprehensive function

2.15” HD LED display. Angle

3.2D/CFM/PDI/PW/M scanning modes

4.Integrated ultrasonic network platform,support DICOM transmit

5.Big capacity built-in lithium battery

6.Embed computer system ensure stabilization safe and fast running.

Functions

Monitor: 15”LED Player

Gray scale: 256 levels.

Depth display: ≥250mm;

Dynamic range: 0~120dB adjustable.

One-click optimization function.

Self-motion optimize function.

Image multiplying factor.

Standard configuration

1 unit main unit
1 pc 3.5MHz convex probe
1 pc Power cable

Optional

1 pc 7.5MHz linear probe
1 pc 6.5MHz transvaginal probe
1 pc 5.0MHz micro-convex probe
1 pc 5.0MHz transrectal probe
1 pc thermal printer
1 pc deluxe cart

Measurement & calculation

B mode	Distance, circumference, area, volume, angle, ratio, and stenos rate
M mode	Heart rate, time, distance, speed, ratio, etc
Gynecology measurement	Uterus, cervix, endometrial, ovary, follicular
Obstetrics measurement	EGA, ETD, fetal weight estimation, AFI index, OB report (including OB tables)
Cardiology measurement	LV measurement
Urology measurement	Prostate volume, displacement volume, bladder capacity, and residual urine output
PW measurements	Time, speed, Heart Rate, RI, PI, etc
Other measurement	Slice volume measurement, hip joint angle measurement

Digital Specification

Image storage	≥160G
Image storage	Image storage, video storage, cine loop
Frequency conversion	2MHz-12MHz(Depending on the probe)
Pseudo color encoding	16 kinds can optional
Gain adjusts	8 segments TGC, B/M/D/C is independently adjustable
E-zoom	magnify 2 times of real time image
Focus position	dynamic electron focusing
Running hours	≥8h
Input power	≤300VA
Host weight	about 6 kg
Host appearance size	370 ×382×90mm

Application	Abdomen, gynecology, obstetrics, superficial organ, urologist, heart Mode and user defined model 1-4, total ten models
Particularly Recommended	USB. VIDEO .DICOME.FOOT SW
Output	USB Port:Our machine can connect the common printer . Used to print the measurement report page
Patient data	Medical record management, report inquiry and printing, image video output( HDD ,USB,Optional DVD-RW),built-in ultrasound workstation
Reporting system	automatic report generation system, and can be full screen characters in both Chinese and English editor
